meanwell RQ Serisi Çok Çıkışlı (Kutulu Tip)

Teklif İste

RQ Serisi Çok Çıkışlı (Kutulu Tip)

Ürün Kodu Güç Çıkış Vdc Çıkış-1 Çıkış-2 Çıkış-3 Çıkış-4 Boyut RQ-50B 50W 5/12/-5/-12V 5V/0.5-5A 12V/0.2-1A -5V/0-0.5A -12V/0-0.5A 99x97x36mm RQ-50C 50W 5/15/-5/-15V 5V/0.5-5A 15V/0.2-1A -5V/0-0.5A -15V/0-0.5A 99x97x36mm RQ-50D 50W 5/12/24/-12V 5V/0.5-3A 12V/0.2-0.9A 24V/0.1-0.9A -12V/0-0.5A 99x97x36mm RQ-65B 65W 5/12/-5/-12V 5V/0.5-6A 12V/0.2-2A -5V/0-0.5A -12V/0-0.5A 129x98x38mm RQ-65C 65W 5/15/-5/-15V 5V/0.5-5A 15V/0.2-2A -5V/0-0.5A -15V/0-0.5A 129x98x38mm RQ-65D 65W 5/12/24/-12V 5V/0.5-4A 12V/0.2-1.5A 24V/0.1-1A -12V/0-0.5A 129x98x38mm RQ-85B 85W 5/12/-5/-12V 5V/2-7A 12V/0.3-3.1A -5V/0-0.5A -12V/0-0.5A 129x98x38mm RQ-85C 85W 5/15/-5/-15V 5V/2-7A 15V/0.3-2.5A -5V/0-0.5A -15V/0-0.5A 129x98x38mm RQ-85D 85W 5/12/24/-12V 5V/2-6A 12V/0.3-2A 24V/0.1-1A -12V/0-0.5A 129x98x38mm RQ-125B 125W 5/12/-5/-12V 5V/2-11A 12V/0.5-4.5A -5V/0-1A -12V/0-0.5A 129x98x38mm RQ-125C 125W 5/15/-5/-15V 5V/2-10A 15V/0.5-4A -5V/0-1A -15V/0-0.5A 129x98x38mm RQ-125D 125W 5/12/24/-12V 5V/2-8A 12V/0.5-2.5A 24V/0.1-2A -12V/0-0.5A 129x98x38mm

Ürün Kodu: Kategori: guc-kaynaklari

Açıklama
Teknik Özellikler

Ürün Açıklaması

Ürün Kodu	Güç	Çıkış Vdc	Çıkış-1	Çıkış-2	Çıkış-3	Çıkış-4	Boyut
RQ-50B	50W	5/12/-5/-12V	5V/0.5-5A	12V/0.2-1A	-5V/0-0.5A	-12V/0-0.5A	99x97x36mm
RQ-50C	50W	5/15/-5/-15V	5V/0.5-5A	15V/0.2-1A	-5V/0-0.5A	-15V/0-0.5A	99x97x36mm
RQ-50D	50W	5/12/24/-12V	5V/0.5-3A	12V/0.2-0.9A	24V/0.1-0.9A	-12V/0-0.5A	99x97x36mm
RQ-65B	65W	5/12/-5/-12V	5V/0.5-6A	12V/0.2-2A	-5V/0-0.5A	-12V/0-0.5A	129x98x38mm
RQ-65C	65W	5/15/-5/-15V	5V/0.5-5A	15V/0.2-2A	-5V/0-0.5A	-15V/0-0.5A	129x98x38mm
RQ-65D	65W	5/12/24/-12V	5V/0.5-4A	12V/0.2-1.5A	24V/0.1-1A	-12V/0-0.5A	129x98x38mm
RQ-85B	85W	5/12/-5/-12V	5V/2-7A	12V/0.3-3.1A	-5V/0-0.5A	-12V/0-0.5A	129x98x38mm
RQ-85C	85W	5/15/-5/-15V	5V/2-7A	15V/0.3-2.5A	-5V/0-0.5A	-15V/0-0.5A	129x98x38mm
RQ-85D	85W	5/12/24/-12V	5V/2-6A	12V/0.3-2A	24V/0.1-1A	-12V/0-0.5A	129x98x38mm
RQ-125B	125W	5/12/-5/-12V	5V/2-11A	12V/0.5-4.5A	-5V/0-1A	-12V/0-0.5A	129x98x38mm
RQ-125C	125W	5/15/-5/-15V	5V/2-10A	15V/0.5-4A	-5V/0-1A	-15V/0-0.5A	129x98x38mm
RQ-125D	125W	5/12/24/-12V	5V/2-8A	12V/0.5-2.5A	24V/0.1-2A	-12V/0-0.5A	129x98x38mm
