meanwell QP Serisi Çok Çıkışlı (Kutulu Tip)

Teklif İste

QP Serisi Çok Çıkışlı (Kutulu Tip)

Ürün Kodu Güç Çıkış Vdc Çıkış-1 Çıkış-2 Çıkış-3 Çıkış-4 Boyut QP-150D 150W 5/12/24/-12V 5V/3-10A 12V/0-4A 24V/0.4-2A -12V/0-0.6A 199x99x50mm QP-150F 150W 5/15/24/-15V 5V/3-10A 15V/0-3A 24V/0.4-2A -15V/0-0.6A 199x99x50mm QP-150-3A 150W 5/3.3/12/-5V 5V/3-10A 3.3V/0-10A 12V/0.4-5A -5V/0-0.6A 199x99x50mm QP-150-3B 150W 5/3.3/12/-12V 5V/3-10A 3.3V/0-10A 12V/0.4-5A -12V/0-0.6A 199x99x50mm QP-150-3C 150W 5/3.3/15/-15V 5V/3-10A 3.3V/0-10A 15V/0.4-5A -15V/0-0.6A 199x99x50mm QP-150-3D 150W 5/3.3/24/-12V 5V/3-10A 3.3V/0-10A 24V/0.3-2.5A -12V/0-0.6A 199x99x50mm QP-200D 200W 5/12/24-12V 5V/3-15A 12V/0-4A 24V/0.4-3A -12V/0-0.7A 215x115x50mm QP-200F 200W 5/15/24/-15V 5V/3-15A 15V/0-3A 24V/0.4-3A -15V/0-0.7A 215x115x50mm QP-200-3A 200W 5/3.3/12/-5V 5V/3-15A 3.3V/0-10A 12V/0.5-6A -5V/0-0.7A 215x115x50mm QP-200-3B 200W 5/3.3/12/-12V 5V/3-15A 3.3V/0-10A 12V/0.5-6A -12V/0-0.7A 215x115x50mm QP-200-3C 200W 5/3.3/15/-15V 5V/3-15A 3.3V/0-10A 15V/0.5-5A -15V/0-0.7A 215x115x50mm QP-200-3D 200W 5/3.3/24/-12V 5V/3-10A 3.3V/0-10A 24V/0.4-4A -12V/0-0.7A 215x115x50mm QP-200-3E 200W 5/3.3/24/-15V 5V/3-10A 3.3V/0-10A 24V/0.4-4A -15V/0-0.7A 215x115x50mm QP-320D 320W 5/12/24/-12V 5V/2.5-20A 12V/0-4A 24V/0.2-3A -12V/0.2-2A 215x115x50mm QP-320F 320W 5/15/24/-15V 5V/2.5-20A 15V/0-3A 24V/0.2-3A -15V/0.2-1.6A 215x115x50mm

Ürün Kodu: Kategori: guc-kaynaklari

Açıklama
Teknik Özellikler

Ürün Açıklaması

Ürün Kodu	Güç	Çıkış Vdc	Çıkış-1	Çıkış-2	Çıkış-3	Çıkış-4	Boyut
QP-150D	150W	5/12/24/-12V	5V/3-10A	12V/0-4A	24V/0.4-2A	-12V/0-0.6A	199x99x50mm
QP-150F	150W	5/15/24/-15V	5V/3-10A	15V/0-3A	24V/0.4-2A	-15V/0-0.6A	199x99x50mm
QP-150-3A	150W	5/3.3/12/-5V	5V/3-10A	3.3V/0-10A	12V/0.4-5A	-5V/0-0.6A	199x99x50mm
QP-150-3B	150W	5/3.3/12/-12V	5V/3-10A	3.3V/0-10A	12V/0.4-5A	-12V/0-0.6A	199x99x50mm
QP-150-3C	150W	5/3.3/15/-15V	5V/3-10A	3.3V/0-10A	15V/0.4-5A	-15V/0-0.6A	199x99x50mm
QP-150-3D	150W	5/3.3/24/-12V	5V/3-10A	3.3V/0-10A	24V/0.3-2.5A	-12V/0-0.6A	199x99x50mm
QP-200D	200W	5/12/24-12V	5V/3-15A	12V/0-4A	24V/0.4-3A	-12V/0-0.7A	215x115x50mm
QP-200F	200W	5/15/24/-15V	5V/3-15A	15V/0-3A	24V/0.4-3A	-15V/0-0.7A	215x115x50mm
QP-200-3A	200W	5/3.3/12/-5V	5V/3-15A	3.3V/0-10A	12V/0.5-6A	-5V/0-0.7A	215x115x50mm
QP-200-3B	200W	5/3.3/12/-12V	5V/3-15A	3.3V/0-10A	12V/0.5-6A	-12V/0-0.7A	215x115x50mm
QP-200-3C	200W	5/3.3/15/-15V	5V/3-15A	3.3V/0-10A	15V/0.5-5A	-15V/0-0.7A	215x115x50mm
QP-200-3D	200W	5/3.3/24/-12V	5V/3-10A	3.3V/0-10A	24V/0.4-4A	-12V/0-0.7A	215x115x50mm
QP-200-3E	200W	5/3.3/24/-15V	5V/3-10A	3.3V/0-10A	24V/0.4-4A	-15V/0-0.7A	215x115x50mm
QP-320D	320W	5/12/24/-12V	5V/2.5-20A	12V/0-4A	24V/0.2-3A	-12V/0.2-2A	215x115x50mm
QP-320F	320W	5/15/24/-15V	5V/2.5-20A	15V/0-3A	24V/0.2-3A	-15V/0.2-1.6A	215x115x50mm
